Application:
A premium quality, multi-purpose hose for industrial air service, compressor lines, pneumatic tools, low-pressure spray and many other applications where oil resistance is needed. Non conductive, minimum electrical resistance greater than (1) megohm per inch of hose length at 1000 V DC.
Tube:Black nitrile, RMA class A (high oil resistance)
Reinforcement: High tensile synthetic yarn
Cover: Red NBR blend, RMA class B
Temperature Range:-29ºC to +80ºC (-20ºF to +180ºF)
| Code | I.D.(Inch) | O.D.(Inch) | W.P.(PSI) | B.P.(PSI) | Max.Length(Ft/Roll) |
| 1005000 | 1/4 | 0.54 | 300 | 900 | 300 |
| 1005001 | 5/16 | 0.64 | 300 | 900 | 300 |
| 1005002 | 3/8 | 0.69 | 300 | 900 | 300 |
| 1005003 | 1/2 | 0.86 | 300 | 900 | 300 |
| 1005004 | 5/8 | 1.02 | 300 | 900 | 300 |
| 1005005 | 3/4 | 1.19 | 300 | 900 | 300 |
| 1005006 | 1 | 1.50 | 300 | 900 | 300 |
| 1005007 | 1-1/4 | 1.80 | 300 | 900 | 300 |
| 1005008 | 1-1/2 | 2.09 | 300 | 900 | 200 |
| 1005009 | 2 | 2.64 | 300 | 900 | 200 |
